Quad zone # 9 , Tosot 30KBTU MACHINE
Tosot - 30'000BTU
Covers up to 1150ft2
21SEER 10HSPF
AHRI - 211164241
MOCP 30A MCA 26A
Main Power Wire Size 10-2 AWG
Pre-Charge Length - 131.2
Max. Number IDU: 4
Compressor Crankcase and Base Pan Heaters include
WIFI
Typical Coverage
7000BTU - 150ft2
9000BTU - 300ft2
12000BTU - 500ft2
18000BTU - 750ft2
24000BTU - 1000ft2
Head Combinations
7 + 7 + 7 + 7 = 28
7 + 7 + 7 + 9 = 30
7 + 7 + 7 + 12 = 33
7 + 7 + 9 + 9 = 32
7 + 9 + 9 + 9 = 34
Quad zone # 10 , Tosot 36KBTU MACHINE
Tosot - 36'000BTU
Covers up to 1650ft2
21SEER 10HSPF
AHRI - 211164242
MOCP 30A MCA 26A
Main Power Wire Size 10-2 AWG
Pre-Charge Length - 131.2
Max. Number IDU: 4
Compressor Crankcase and Base Pan Heaters include
WIFI
Typical Coverage
7000BTU - 150ft2
9000BTU - 300ft2
12000BTU - 500ft2
18000BTU - 750ft2
24000BTU - 1000ft2
Head Combinations
7 + 7 + 7 + 12 = 33
7 + 9 + 9 + 9 = 34
7 + 7 + 9 + 12 = 35
9 + 9 + 9 + 9 = 36
7 + 9 + 9 + 12 = 37
7 + 7 + 12 + 12 = 38
7 + 7 + 7 + 18 = 39
9 + 9 + 9 + 12 = 39
Quad zone # 11 , Tosot 42KBTU MACHINE
Tosot - 42'000BTU
Covers up to 1900ft2
21SEER 10HSPF
AHRI - 211164243
MOCP 30A MCA 26A
Main Power Wire Size 10-2 AWG
Pre-Charge Length - 131.2
Max. Number IDU: 5
Compressor Crankcase and Base Pan Heaters include
WIFI
Typical Coverage
7000BTU - 150ft2
9000BTU - 300ft2
12000BTU - 500ft2
18000BTU - 750ft2
24000BTU - 1000ft2
Head Combinations
7 + 7 + 12 + 12 = 38
7 + 7 + 7 + 18 = 39
9 + 9 + 9 + 12 = 39
7 + 9 + 12 + 12 = 40
7 + 7 + 9 + 18 = 41
9 + 9 + 12 + 12 = 42
7 + 12 + 12 + 12 = 43
9 + 9 + 9 + 18 = 45
7 + 9 + 12 + 18 = 46
12 + 12 + 12 + 12 = 48
